GESTENER DSc525, DSc530, DSc520, LANIER LD425c, LD430c, LD420c, RICOH Aficio MP C2500, C3000, C2000, SAVIN C2525, C3030, C2020 Service Manual and Parts Manual

$11.00

Note: Up to 5 downloads only. Make sure to save your copy.

Compare
SKU: 8898 Categories: Gestetner, Lanier, Manuals, Ricoh, Savin

Description

SERVICE MANUAL TABLE OF CONTENTS

Read This First
Safety Notices
Symbols, Abbreviations and Trademarks

Table of Contents
1. Installation
Installation Requirements
Optional Unit Combinations
Copier Installation
Paper Feed Unit (B800)
LCT (B801)
Auto Reverse Document Feeder (B789)
1-Bin Tray Unit (B790)
Shift Tray Unit (B791)
Bridge Unit (B227)
500-Sheet Finisher (B792)
1000-Sheet Finisher (B408)
1000-Sheet Booklet Finisher (B793)
Punch Unit
Mechanical Counter (NA Only)
Key Counter Bracket
Key Counter Interface Unit
Anti-Condensation Heater (Scanner)
Tray Heater
Controller Options

2. Preventive Maintenance
Settings
Maintenance Tables

3. Replacement and Adjustment
Beforehand
Special Tools
Image Adjustment
Exterior Covers
Scanner Unit
Laser Optics
Image Creation
Image Transfer
Paper Transfer
Drive Unit
Fusing
Paper Feed
Duplex Unit
Electrical Components

4. Troubleshooting
Process Control Error Conditions
Scanner Test Mode
Service Call Conditions
SC Table
Troubleshooting Guide
Jam Detection
Electrical Component Defects

5. Service Tables
Service Program Mode
Copy Service Mode
Printer Service Mode
Scanner Service Mode
Reboot/System Setting Reset
Firmware Update
SD Card Appli Move
Controller Self-Diagnostics
Using the Debug Log
Dip Switches

6. Detailed Section Descriptions
Overview
Process Control
Scanning
Image Processing
Laser Exposure
PCU (Photo Conductor Unit)
Toner Supply
Waste Toner Collection
Image Transfer and Paper Separation
Paper Feed
Fusing
Paper Exit
Duplex Unit
Printer Functions
PictBridge
Copy Data Security Unit
File Format Converter (MLB)
Data Overwrite Security Unit (B735)

7. Specifications
General Specifications
Printer
Scanner
Supported Paper Sizes
Software Accessories
Machine Configuration
Optional Equipment
