HP Color Laserjet 3000, 3600, 3800, CP3505 Series Service Manual with Parts Manual

Request a Copier Quote
Home » Shop » HP Color Laserjet 3000, 3600, 3800, CP3505 Series Service Manual with Parts Manual
HP CLJ Clear Choice Technical

HP Color Laserjet 3000, 3600, 3800, CP3505 Series Service Manual with Parts Manual

$11.00

Note: Up to 5 downloads only. Make sure to save your copy.

Compare
SKU: 9648 Categories: HP, Manuals Tags: 3000, 3600, 3800, CP3505

Description

Service Manual Table of Contents

1. Product information
Quick access to printer information
Printers at a glance
Features at a glance
Walkaround
Control-panel overview
Printer software
Print-media specifications

2. Installation and configuration
What is in the box
Site requirements
Connecting to a network or a computer
Printer memory

3. Maintenance
Understanding approximate supplies-replacement
intervals
Replacing supplies
Managing the print cartridge
Cleaning the printer
Calibrating the printer
Tools for troubleshooting

4. Theory of operation
Engine control system
Laser/scanner system
Pickup-and-feed-system
Image-formation system

5. Removal and replacement
Removal and replacement strategy
External doors, covers, and panels
Internal assemblies
Printed circuit assemblies (PCAs)
Sensors
500-sheet feeder

6. Troubleshooting
Troubleshooting process
Control-panel messages
Jams
Image defects
Repetitive-defects troubleshooting
Interface troubleshooting
Service menu
Diagnostics menu
Diagnostics
Test pages
Engine resets
Service ID

7. Parts and diagrams
Ordering parts and supplies
External panels and covers
Internal components
Paper-pickup drive assembly
Duplexing-feed drive assembly (duplex models)
Duplexing reverse-drive assembly (duplex models)
Developing separation-drive assembly
Fuser drive assembly
Cassette (tray 2)
Paper-pickup assembly (HP CLJ 3600/3800/CP3505)
Paper-pickup assembly (HP CLJ 3000)
Electronic transfer belt (simplex models)
Electronic transfer belt (duplex models)
Multipurpose tray assembly (tray 1)
Duplex-paper feed assembly (duplex models)
Fuser
PCAs
500-sheet feeder cassette (tray 3)
500-sheet feeder paper-pickup assembly
500-sheet feeder PCA
Alphabetical parts list
Numerical parts list

A. Printer specifications
Electrical specifications
Power-consumption specifications
Acoustic specifications
Operating-environment specifications

B. Product warranty statements
Hewlett-Packard Limited Warranty Statement
Availability of support and service
HP maintenance agreements

C. Regulatory statements
FCC regulations
Declaration of conformity (HP Color LaserJet 3000 Series
printer)
Declaration of conformity (HP Color LaserJet 3600 Series
and HP Color LaserJet 3800 Series printer)
Declaration of conformity (HP Color LaserJet CP3505
Series printer)
Safety statements

Index
