KONICA MINOLTA Bizhub C360, C280 and C220 Service Manual and Parts Manual

Note: Up to 5 downloads only. Make sure to save your copy.

$9.00

SERVICE MANUAL TABLE OF CONTENTS

SAFETY AND IMPORTANT WARNING ITEMS
IMPORTANT NOTICE
DESCRIPTION ITEMS FOR DANGER, WARNING AND CAUTION
SAFETY WARNINGS
WARNING INDICATIONS ON THE MACHINE

MEASURES TO TAKE IN CASE OF AN ACCIDENT
Composition of the service manual
Notation of the service manual

bizhub C360/C280/C220 Main Unit
OUTLINE
MAINTENANCE
ADJUSTMENT/SETTING
TROUBLESHOOTING
APPENDIX

i-Option LK-101 v2/102/103 v2/105
OUTLINE
ADJUSTMENT/SETTING
TROUBLESHOOTING

DF-617/SP-501
OUTLINE
MAINTENANCE
ADJUSTMENT/SETTING

PC-107/PC-207
OUTLINE
ADJUSTMENT/SETTING

PC-408
OUTLINE
MAINTENANCE
ADJUSTMENT/SETTING

JS-505
OUTLINE
MAINTENANCE

FS-527
OUTLINE
MAINTENANCE

PK-517
OUTLINE
MAINTENANCE
ADJUSTMENT/SETTING

SD-509
OUTLINE
MAINTENANCE
ADJUSTMENT/SETTING

JS-603
OUTLINE
MAINTENANCE

FS-529
OUTLINE
MAINTENANCE



bizhub C360/C280/C220 Main Unit

OUTLINE
1. System configuration

2. Product specifications
2.1 Type
2.2 Functions
2.3 Paper
2.4 Materials
2.5 Print Volume
2.6 Machine Specifications
2.7 Operating Environment
2.8 Print Functions
2.9 Scan Functions

MAINTENANCE
3. Periodical Maintenance Items
3.1 Concept of Periodical Maintenance
3.2 Periodical replacement parts list
3.3 Periodical cleaning parts list
3.4 Concept of parts life

4. Periodical Maintenance Procedure
4.1 Housing Section
4.2 Photo conductor section
4.3 Charging section
4.4 Developing section
4.5 Toner supply section
4.6 1st transfer section
4.7 2nd transfer/separation section
4.8 Toner collection section
4.9 Paper feed section
4.10 Registration section
4.11 Fusing Section
4.12 Duplex section

5. Other Maintenance Items
5.1 Disassembly/adjustment prohibited items
5.2 Notes when transporting the machine
5.3 Disassembly/reassembly parts list
5.4 Cleaning parts list
5.5 Disassembly/reassembly procedure
5.6 Cleaning Procedure

6. Service Tool
6.1 Service Material List
6.2 CE Tool List

7. Firmware Rewriting
7.1 Outline
7.2 USB memory
7.3 Updating the firmware with the internet ISW

8. Commercially Available Parts
8.1 Installing the key counter
8.2 Installing the original size detection 2 sensor (PS205)

ADJUSTMENT/SETTING
9. How to use the Adjustment/Setting Section

10. Utility
10.1 List of utility mode
10.2 Starting/Exiting
10.3 Touch Panel Adjustment
10.4 One-Touch User Box Registration
10.5 User Settings
10.6 Administrator Settings
10.7 Banner Printing
10.8 Panel SEttings
10.9 Device Information

11. Adjustment Item List

12. Service Mode
12.1 List of service mode
12.2 Starting/Exiting
12.3 Date/Time Input mode
12.4 Machine
12.5 Firmware Version
12.6 Image Process Adjustment
12.7 CS Remote Care
12.8 System 1
12.9 System 2
12.10 Counter
12.11 List Output
12.12 State Confirmation
12.13 Test Mode
12.14 ADF
12.15 FAX
12.16 Finisher
12.17 Internet ISW

13. Enhanced Security
13.1 List of Enhanced Security
13.2 Starting/Exiting
13.3 Enhanced Security

14. Billing Setting
14.1 List of Billing Setting
14.2 Starting/Exiting
14.3 Billing Setting

15. Contents To Be Cleared By Reset Function

16. Mechanical Adjustment
16.1 Mechanical Adjustment of the scanner section
16.2 Mechanical Adjustment of the paper feed section

TROUBLESHOOTING
17. Jam Display
17.1 List of JAM Code
17.2 Sensor Layout
17.3 Solution

18. Malfunction Code
18.1 Display Procedure
18.2 List
18.3 Solution

19. Trouble Code
19.1 Display Procedure
19.2 Trouble resetting procedure
19.3 Trouble isolation function
19.4 List
19.5 Solution

20. Network Error Code
20.1 Display Procedure
20.2 List

21. Power Supply Trouble
21.1 Machine is not energized at all (DCPU operation check)
21.2 Fusing heaters do not operate
21.3 Power is not supplied to option

22. Image Quality Problem
22.1 How to read element date
22.2 How to identify problematic part
22.3 Solution

23. IC Protector
23.1 Outline
23.2 IC Protector List

APPENDIX

24. Parts Layout Drawing
24.1 Main body
24.2 DF-617/SP-501
24.3 PC-107/PC-207(Option)
24.5 JS-505 (Option)
24.6 FS-527 (Option)
24.7 PK-517 (Option)
24.8 SD-509 (Option)
24.9 JS-603 (Option)
24.10 FS-529 (Option)

25. Connector Layout Drawing
25.1 Main body

26. Relay Connector Layout Drawing
26.1 How to read the relay connector layout drawing
26.2 Main body

27. Timing Chart
27.1 Main body
27.2 DF-617
27.3 FS-527/SD-509/PK-517
27.4 JS-603
27.5 FS-529

PARTS MANUAL TABLE OF CONTENTS

1 EXTERNAL PARTS P1 P2 P3
2 IR COVER P4
3 CONTROL PANEL P5
4 CCD UNIT/ SCANNER SECTION P6
5 SCANNER DRIVE SECTION P7 P8
6 IR FRAME P9
7 PH UNIT P10
8 TONER SUPPLY SECTION P11 P12
9 D/C RAIL SECTION P13
10 ERASE LAMP SECTION P14
11 TRANSFER BELT UNIT P15
12 1ST PAPER FEED SECTION P16 P17
13 2ND PAPER FEED SECTION P18 P19
14 PAPER FEED DRIVE P20
15 1ST CASSETTE SECTION P21 P22
16 2ND CASSETTE SECTION P23 P24
17 VERTICAL CONVEYANCE DOOR SECTION P25 P26 P27 P28
18 MANUAL FEED TRAY UNIT P29 P30
19 VERTICAL CONVEYANCE SECTION P31 P32 P33
20 FUSING SECTION/ WASTE TONER BOX P34
21 PAPER EXIT SECTION P35
22 MAIN DRIVE SECTION P36
23 FUSING DRIVE SECTION P37
24 BOTTLE DRIVE SECTION P38
25 CASSETTE RAIL SECTION P39
26 MAIN POWER SUPPLY UNIT P40
27 HIGH VOLTAGE UNIT P41
28 REAR FAN SECTION P42
29 SHIELD BOX P43
30 WIRING P44 P45 P46 P47
31 WIRING ACCESSORIES AND JIGS P48
32 ACCESSORY PARTS
