BROTHER DCP-7090, 7095, D7190DN, 7195DW, DCP-B7500D, B7520DWB, 7530DN, B7535DW, DCP-L2510, DL2511, DL2512, DL2530DW, DCP-L2531DW, L2532DW, L2535, DL2535DW, DCP-L2536D, L2537DW, L2550DN, L2550DW, DCP-L2551DN, L2551DW, L2552DN, HL-L2390DW, L2395DW, MFC-7390, 7490D, 7890DN, 7895DW, MFC-B7700D, B7715DW, B7720DN, MFC-L2690DW, L2710DN, L2710DW, L2712DN, MFC-L2712DW, L2713DW, L2715D, L2715DW, MFC-L2716D, L2716DW, L2717DW, MFC-L2730DW, L2732DW, L2750DW, L2750DWXL, MFC-L2751DW, L2752DW, L2770DW, L2771DW Service Manual and Parts Manual

$9.00

SERVICE MANUAL TABLE OF CONTENTS

SAFETY INFORMATION
CHAPTER 1 SUPPLEMENTAL SPECIFICATIONS
1. GENERAL
2. NETWORK CONNECTIVITY
3. SERVICE INFORMATION
4. SUPPLIES
5. MEDIA SPECIFICATIONS
6. FAX (ONLY FOR THE MODELS WITH FAX FUNCTION)
7. COPY
8. SCANNER

CHAPTER 2 ERROR INDICATIONS AND TROUBLESHOOTING
1. INTRODUCTION
2. OVERVIEW
3. ERROR INDICATIONS
4. TROUBLESHOOTING

CHAPTER 3 DISASSEMBLY/REASSEMBLY
1. SAFETY PRECAUTIONS
2. PACKING
3. SCREW CATALOGUE
4. SCREW TORQUE LIST
5. LUBRICATION
6. OVERVIEW OF GEARS
7. HARNESS ROUTING
8. DISASSEMBLY FLOW CHART
9. DISASSEMBLY PROCEDURE

CHAPTER 4 ADJUSTING AND UPDATING SETTINGS AS REQUIRED AFTER PARTS REPLACEMENT
1. IF YOU REPLACE THE MAIN PCB ASSY
2. IF YOU REPLACE THE LOW-VOLTAGE POWER SUPPLY PCB ASSY
3. IF YOU REPLACE THE LASER UNIT
4. IF YOU REPLACE THE PANEL UNIT OR PANEL CONTROL
5. IF YOU REPLACE THE ADF UNIT, FIRST SIDE CIS UNIT, SECOND SIDE CIS UNIT OR DOCUMENT SCANNER UNIT

CHAPTER 5 SERVICE FUNCTIONS
1. FUNCTION CODE
2. OTHER SERVICE FUNCTIONS

CHAPTER 6 WIRING DIAGRAM
1. WIRING DIAGRAM

CHAPTER 7 PERIODICAL MAINTENANCE
1. PERIODICAL REPLACEMENT PARTS

APPENDIX 1 SERIAL NUMBERING SYSTEM
APPENDIX 2 DELETING USER SETTING INFORMATION
APPENDIX 3 INSTALLING THE MAINTENANCE PRINTER DRIVER

PARTS MANUAL TABLE OF CONTENTS

1. FRAME L & DRIVE UNIT
2. PAPER FEEDER
3. FRAME
4. LASER UNIT
5. DX
6. PAPER CASSETTE
7. FUSER UNIT
8. COVERS& LABELS
9. DOCUMENT SCANNER
10. ADF & DOCUMENT COVER
11. PANEL
12. PCB
13. ACCESSORIES
14. PACKING MATERIALS
